6314/2TDH4P ebm-papst

Name: 6314/2TDH4P ebm-papst
Brand: APAC FAN
SKU: 6314/2TDH4P
Price: 140.75 USD
Availability: InStock

No.6314/2TDH4P

4.8 (0)

85 Sold

$140.75

ebm-papst,Compact Fan,927m³/h,150W,9200RPM,1050Pa,24V,φ172*51mm,

Received successfully

Coupon Code

1/1

Brand：	ebm-papst
Part No：	6314/2TDH4P
Fan Type：	Compact Fan
Rated Voltage(V)：	24
Size(mm)：	φ172*51
Max.Air Flow(m³/h)：	927
Max.Pressure(Pa)：	1050
Input Power(W)：	150
Speed(rpm)：	9200
Rotating Direction Looking At Rotor:	Counterclockwise
Airflow Direction:	Air outlet over struts
Bearing System:	Ball bearing
Mounting Position - Shaft:	Any
Mass:	0,875 kg
Housing Material:	Metal
Impeller Material:	Plastic
Max. Torque When Mounted Across Both Mounting Flanges:	- Wire outlet corner: 600 Ncm - Remaining corners: 600 Ncm
Screw Size:	ISO 4762 - M4 degreased, without an additional brace and without washer
