| Brand： | ebm-papst |
| Part No： | K3G097-AS82-82 |
| Fan Type： | Centrifugal Fan |
| Rated Voltage(V)： | 26 |
| Size(mm)： | 97 |
| Max.Air Flow(m³/h)： | N/A |
| Max.Pressure(Pa)： | N/A |
| Input Power(W)： | 740 |
| Speed(rpm)： | 4680 |
| Noise(dB)： | N/A |
| Weight: | 2.3 kg |
| Motor Size: | 84 |
| Impeller Material: | PA plastic UL94 V0 |
| Housing Material: | PA plastic UL94 V0 |
| Direction of Rotation: | Clockwise, viewed toward rotor |
| Degree of Protection: | Motor IP24 KM, electronics IP6K9K (mating connector installed) |
| Insulation Class: | "B" |
| Moisture (F) / Environmental (H) Protection Class: | H3 |
| Installation Position: | Any |
| Condensation Drainage Holes: | None, open rotor |
| Mode: | S1 |
| Motor Bearing: | Ball bearing; (sealed) |
| Technical Features: | - Fault output (open collector) - Load dump (58 V) - Motor current limitation - Soft start - Control input 0-10 VDC / PWM - Temperature derating (Fault message via diagnostic output in derating operation) - Overvoltage detection - Thermal overload protection for electronics - Reverse polarity protection |
| Electrical Hookup: | Standby current less than 500 µA |
| Protection Class Assignment: | III; Requires supply with safety extra-low voltage SELV. This component for installation may have several local protection classes. This information relates to this component’s basic design. The final protection class is based on the component’s intended installation and connection. |
| Conformity with Standards: | EN 15085-1, CPC3; EN 45545-2, HL3; EN 50155; EN 61373, Cat. 1B |
| Approval: | EAC |
