K3G190-RD45-03 ebm-papst

Name: K3G190-RD45-03 ebm-papst
Brand: APAC FAN
SKU: K3G190-RD45-03
Price: 255.9 USD
Availability: InStock
Rating: 5.0 (3 reviews)

No.K3G190-RD45-03

5.0 (3)

134 Sold

$255.90

The ebm-papst K3G190-RD45-03 is a premium 190mm EC backward-curved centrifugal fan designed for precision ventilation.
EC Technology: Powered by a high-efficiency 230V, 169W EC motor reaching 4120rpm.
Air Performance: Delivers up to 524m³/h airflow with strong static pressure capability.
Smart Control: Supports stepless speed modulation to match dynamic cooling loads.
Ready to Ship: 100% authentic original, brand new in stock for fast worldwide delivery.

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites (11)

1/1

Description

Brand：	ebmpapst
Part No：	K3G190-RD45-03
Fan Type：	Centrifugal Fan
Rated Voltage(V)：	230
Size(mm)：	190
Max.Air Flow(m³/h)：	524
Max.Pressure(Pa)：	N/A
Input Power(W)：	169
Speed(rpm)：	4120
Noise(db)：	N/A
Min. ambient temperature (°C):	-25
Max. ambient temperature (°C):	60
Material of impeller:	PA plastic
Housing material	PA plastic
Direction of rotation:	Clockwise, viewed toward rotor
Type of protection:	IP54
Insulation class:	B
Motor bearing:	Ball bearing
Product conforming to standard:	EN 60335-1; CE
Approval:	CSA C22.2 No. 77; UL 2111; EAC; CCC
