FAQ
Q1: How does the 1800 Pa maximum pressure of the K3G500-PC16-N1 meet the demands of high-resistance industrial ventilation systems?
A1: The K3G500-PC16-N1 centrifugal fan delivers an impressive 1800 Pa maximum pressure, paired with a 19450 m³/h maximum air flow, making it ideal for high-resistance industrial systems. Operating at 2400 RPM with 7000 W input power, this 500mm fan can push large air volumes through long duct runs, dense filtration setups, and complex airflow paths common in heavy manufacturing, mining ventilation, and large-scale HVAC systems. Its pressure capability ensures consistent air distribution even under the most demanding resistance conditions.
Q2: What is the noise level of the K3G500-PC16-N1, and how to mitigate its sound output in noise-sensitive environments?
A2: The K3G500-PC16-N1 operates at a noise level of 84 dB, a typical figure for a heavy-duty industrial centrifugal fan with its high airflow and pressure outputs. To reduce noise in semi-sensitive environments like industrial workshops with nearby offices, users can install sound-dampening enclosures around the fan, use acoustic insulation in ductwork, or opt for variable frequency drives to lower RPM during low-demand periods. These measures balance the fan’s robust performance with reduced sound pollution.
Q3: How does the 500mm size of the K3G500-PC16-N1 contribute to its high airflow and pressure performance?
A3: The 500mm size of the K3G500-PC16-N1 is a core factor in its high-performance output, as it enables a larger blade sweep area that moves more air per rotation. Combined with a 2400 RPM operating speed, this size supports a 19450 m³/h maximum airflow and 1800 Pa peak pressure, which are essential for large-scale applications. The fan’s size also allows for a more robust motor and housing design that can handle the 7000 W input power required for heavy-duty continuous operation in industrial settings.
Q4: What power supply requirements does the K3G500-PC16-N1 have, and how does it fit into industrial electrical systems?
A4: The K3G500-PC16-N1 is rated for a 400V power supply, which aligns with standard three-phase industrial electrical grids used globally in manufacturing, warehousing, and large commercial facilities. With a 7000 W input power, it requires dedicated electrical circuits to ensure stable operation and avoid overloads. This voltage compatibility eliminates the need for costly voltage conversion equipment, simplifying integration into existing industrial ventilation and cooling systems while delivering the high power needed for its performance metrics.
Q5: In what specific large-scale industrial applications can the K3G500-PC16-N1 deliver optimal performance?
A5: The K3G500-PC16-N1 excels in large-scale industrial applications that demand high airflow and pressure, including heavy machinery cooling in steel mills, dust and fume extraction in welding workshops, and air handling for large data centers with dense server layouts. Its 19450 m³/h airflow ensures massive air exchange, while the 1800 Pa pressure overcomes resistance from filtration and ducting. The 84 dB noise level is manageable in industrial zones, and its 400V compatibility makes it a reliable choice for heavy-duty continuous operation.
