| Brand: | NICOTRA |
| Part No: | PA-C50-LM56-C0000 |
| Fan Type: | Centrifugal Fan |
| Rated Voltage(V): | 3~ 380-480 |
| Max.Air Flow(m³/h): | 12015 |
| Max.Pressure(Pa): | 1620 |
| Input Power(W): | 7800 |
| Speed(RPM): | 2450 |
| Design Variant: | Plug |
| Nominal Impeller Diameter: | 500 mm |
| Air Flow: | 7071 cfm |
| Pressure Rise: | 6.50 in wg |
| Max Fan Speed: | 2450 rpm |
| Nominal Voltage: | 460 V |
| Nominal Current: | 10.3 (460V) A |
| Current Range: | 12.4 - 9.8 A |
| Phase: | 3 |
| Frequency: | 50/60 Hz |
| Impeller Type: | Centrifugal Radial Tip |
| Overall Efficiency: | 72.8 % |
| Number of Fan Blades: | 5 |
| Motor Power Input: | 9.96 Hp |
| Impeller Material: | Aluminum |
| Installation Orientation: | Vertical or Horizontal |
| Rotation Direction: | Counterclockwise |
| Installation Category: | A |
| Motor & Control Material: | Cast Aluminum |
| Efficiency Category: | Static |
| Ambient Operating Temp Range: | -20 to +40 °C |
| Achieved Efficiency Grade (N 74.1 ist): | |
| Electrical Type: | ECM |
| Required Efficiency Grade in 2013/2015 (N): | 58/62 |
| Type of Protection: | Self Protected Control |
| ODE Bearing Type: | Deep Groove Ball |
| Insulation Class: | F |
| IP Code: | 54 |
| DE Bearing Type: | Deep Groove |
| Specific Ratio: | 1.016 |
| UL: | Yes |
| CE: | Yes |
