| Brand： | ebm-papst |
| Part No： | R3G220-RC05-06 |
| Fan Type： | Centrifugal Fan |
| Rated Voltage(V)： | 230 |
| Size(mm)： | 220 |
| Max.Air Flow(m³/h)： | N/A |
| Max.Pressure(Pa)： | N/A |
| Input Power(W)： | 85 |
| Speed(rpm)： | 2580 |
| Noise(dB)： | N/A |
| Weight: | 0.97 kg |
| Rotor Surface: | Unpainted |
| Impeller Material: | PA plastic |
| Number of Blades: | 7 |
| Direction of Rotation: | Clockwise, viewed toward rotor |
| Degree of Protection: | IP54 |
| Insulation Class: | "B" |
| Moisture (F) / Environmental (H) Protection Class: | H1 |
| Installation Position: | Any |
| Condensation Drainage Holes: | None, open rotor |
| Mode: | S1 |
| Motor Bearing: | Ball bearing |
| Technical Features: | - Motor current limitation - Soft start - Thermal overload protection for electronics/motor |
| Touch Current according to IEC 60990 (measuring circuit Fig. 4, TN system): | <= 3.5 mA |
| Electrical Hookup: | With plug |
| Motor Protection: | Electronic motor protection |
| Cable: | Variable |
| Protection Class: | I (with customer connection of protective earth) |
| Conformity with Standards: | EN 60335-1; CE |
| Approval: | CCC; C22.2 No.77 + CAN/CSA-E60730-1; UL 1004-7 + 60730 |
