forward-curved, dual-intake with housing (without flange)
| Brand： | ebm-papst |
| Part No： | D2E133-CI33-56 |
| Fan Type： | Centrifugal Fan |
| Rated Voltage(V)： | 230 |
| Size(mm)： | 133 |
| Max.Air Flow(m³/h)： | 515 |
| Max.Pressure(Pa)： | 200 |
| Input Power(W)： | 190 |
| Speed(rpm)： | 2100 |
| Weight: | 3.3 kg |
| Rotor Surface: | Partly cast in aluminum |
| Impeller Material: | Sheet steel, hot-dip galvanized |
| Housing Material: | Sheet steel, hot-dip galvanized |
| Direction of Rotation: | Counterclockwise, viewed toward rotor |
| Degree of Protection: | IP44; installation- and position-dependent |
| Insulation Class: | "B" |
| Moisture (F) / Environmental (H) Protection Class: | H0 - dry environment |
| Max. Permitted Ambient Temp. for Motor (Transport/Storage): | + 80 °C |
| Min. Permitted Ambient Temp. for Motor (Transport/Storage): | - 40 °C |
| Installation Position: | Any |
| Condensation Drainage Holes: | None |
| Mode: | S1 |
| Motor Bearing: | Ball bearing |
| Touch Current according to IEC 60990 (measuring circuit Fig. 4, TN system): | < 0.75 mA |
| Motor Protection: | Thermal overload protector (TOP) internally connected |
| With Cable: | Axial |
| Protection Class: | I (with customer connection of protective earth) |
| Conformity with Standards: | EN 60335-1; CE |
| Approval: | CCC; EAC |
