| Brand： | ebm-papst |
| Part No： | D4E133-AA01-44 |
| Fan Type： | Centrifugal Fan |
| Rated Voltage(V)： | 230 |
| Size(mm)： | 133 |
| Input Power(W)： | 80 |
| Speed(RPM)： | 1200 |
| Weight: | 2.7 kg |
| Impeller Material: | Sheet steel, galvanized |
| Housing Material: | Sheet steel, hot-dip galvanized |
| Motor Suspension: | Motor mounted with brackets on one side |
| Direction of Rotation: | Clockwise, viewed toward rotor |
| Degree of Protection: | IP44; installation- and position-dependent |
| Insulation Class: | "B" |
| Moisture (F) / Environmental (H) Protection Class: | H0 - dry environment |
| Installation Position: | Any |
| Condensation Drainage Holes: | None |
| Mode: | S1 |
| Motor Bearing: | Ball bearing |
| Touch Current According to IEC 60990 (Measuring Circuit Fig. 4, TN System): | < 0.75 mA |
| Motor Protection: | Thermal overload protector (TOP) internally connected |
| Cable Exit: | Axial |
| Protection Class: | I (with customer connection of protective earth) |
| Conformity with Standards: | EN 60335-1; CE |
| Approval: | UL 1004-3; CSA C22.2 No. 77 |
