| Brand： | ebm-papst |
| Part No： | D4E180-CA02-02 |
| Fan Type： | Centrifugal Fan |
| Rated Voltage(V)： | 230 |
| Size(mm)： | 180 |
| Input Power(W)： | 495 |
| Speed(rpm)： | 1280 |
| Weight: | 10.24 kg |
| Motor Size: | 68 |
| Rotor Surface: | Painted black |
| Impeller Material: | Sheet steel, galvanized |
| Housing Material: | Sheet steel, galvanized |
| Motor Suspension: | Motor vibration-damped on both sides |
| Direction of Rotation: | Counterclockwise, viewed toward rotor |
| Degree of Protection: | IP54 |
| Insulation Class: | "B" |
| Moisture (F) / Environmental (H) Protection Class: | H1+ |
| Installation Position: | Any |
| Condensation Drainage Holes: | None |
| Mode: | S1 |
| Motor Bearing: | Ball bearing |
| Touch Current according to IEC 60990 (measuring circuit Fig. 4, TN system): | < 0.75 mA |
| Motor Protection: | Thermal overload protector (TOP) internally connected |
| Protection Class: | I (with customer connection of protective earth) |
| Conformity with Standards: | EN 60335-1 |
| Approval: | CCC; EAC |
