forward curved, single inlet with housing (flange)
| Brand： | ebm-papst |
| Part No： | G2E108-AA01-01 |
| Fan Type： | Centrifugal Fan |
| Rated Voltage(V)： | 230 |
| Size(mm)： | 108 |
| Max.Air Flow(m³/h)： | 155 |
| Max.Pressure(Pa)： | 260 |
| Input Power(W)： | 44 |
| Speed(rpm)： | 1650 |
| Mass: | 1.3 kg |
| Material of Impeller: | Sheet steel, hot-galvanised |
| Housing Material: | Die-cast aluminium |
| Direction of Rotation: | Clockwise, seen on rotor |
| Type of Protection: | IP 44; Depending on installation and position |
| Insulation Class: | "B" |
| Max. Permissible Ambient Motor Temp. (Transp./ Storage): | + 80 °C |
| Min. Permissible Ambient Motor Temp. (Transp./Storage): | - 40 °C |
| Mounting Position: | Any |
| Condensate Discharge Holes: | None |
| Operation Mode: | S1 |
| Motor Bearing: | Ball bearing |
| Touch Current acc. IEC 60990 (Measuring Network Fig. 4, TN System): | < 0.75 mA |
| Motor Protection: | Thermal overload protector (TOP) wired internally |
| Protection Class: | I (if protective earth is connected by customer) |
| Product Conforming to Standard: | EN 60335-1; CE |
| Approval: | CCC; EAC |
