| Brand: | ebm-papst |
| Part No: | G2E140-PI51-11 |
| Fan Type: | Centrifugal Fan |
| Rated Voltage(V): | 230 |
| Size(mm): | 140 |
| Input Power(W): | 180 |
| Speed(RPM): | 2200 |
| Weight: | 3.3 kg |
| Motor Size: | 68 |
| Rotor Surface: | Painted black |
| Impeller Material: | Sheet steel, painted black |
| Housing Material: | Sheet steel, galvanized |
| Direction Of Rotation: | Counterclockwise, viewed toward rotor |
| Degree Of Protection: | IP44; installation- and position-dependent as per EN 60034-5 |
| Insulation Class: | "B" |
| Moisture (F) / Environmental (H) Protection Class: | H1 |
| Installation Position: | Shaft horizontal or rotor on bottom; rotor on top on request |
| Condensation Drainage Holes: | On rotor side |
| Mode: | S1 |
| Motor Bearing: | Ball bearing |
| Touch Current According To IEC 60990 (Measuring Circuit Fig. 4, TN System): | < 0.75 mA |
| Motor Protection: | Thermal overload protector (TOP) with basic insulation |
| With Cable: | Variable |
| Protection Class: | I (with customer connection of protective earth) |
| Conformity With Standards: | EN 60335-1 |
| Approval: | EAC |
