backward curved
| Brand： | ebm-papst |
| Part No： | R2D225-AT26-15 |
| Fan Type： | Centrifugal Fan |
| Rated Voltage(V)： | 400 |
| Fan size(mm)： | 225 |
| Max.Air Flow(m³/h)： | 1035 |
| Max.Pressure(Pa)： | 492 |
| Input Power(W)： | 130 |
| Speed(rpm)： | 3100 |
| Leackage Current : | < 0.75 mA |
| Operation Mode : | S1 |
| Direction of Rotation : | Clockwise, seen on rotor |
| Mounting Position : | Any |
| Humidity Class : | F2-2 |
| Insulation Class : | "B" |
| Cable Exit : | Lateral |
| Condensate Discharge Holes : | None |
| Bearing Motor : | Ball bearing |
| Mass : | 2.15 kg |
| Material of Impeller : | PA plastic 6, fibreglass-reinforced |
| Motor Protection : | Thermal overload protector (TOP) brought out |
| Product Conforming to Standard : | CE |
| Surface of Rotor : | Coated in black |
| Number of Blades : | 11 |
| Type of Protection : | IP 44; Depending on installation and position |
| Protection Class : | I |
| Max. Permissible Ambient Motor Temp. (Transp./ Storage) : | + 80 °C |
| Min. Permissible Ambient Motor Temp. (Transp./Storage) : | - 40 °C |
| Approval : | CCC; CSA C22.2 Nr.100; UL 1004-1; VDE |
