| Brand： | ebmpapst |
| Part No： | G3G250-GN17-01 |
| Fan Type： | Centrifugal Fan |
| Rated Voltage(V)： | 230 |
| Size(mm)： | 250 |
| Max.Air Flow(m³/h)： | 1655 |
| Max.Pressure(Pa)： | 2900 |
| Input Power(W)： | 1117 |
| Speed(rpm)： | 5005 |
| Noise(db)： | 79 |
In the field of ventilation and air treatment, centrifugal fans play a crucial role. As a well-known brand in the industry, ebm-papst's G3G250-GN17-01 centrifugal fan has attracted much attention in the market due to its advanced technology and excellent performance. This article will provide a comprehensive and detailed introduction to the fan, covering its parameters, characteristics, and other aspects, to provide users with a comprehensive and in-depth understanding.
ebm-papst is a company with a deep history and excellent reputation, possessing leading technology and rich experience in the field of wind turbine manufacturing. G3G250-GN17-01, as one of its centrifugal fans, is designed to meet the ventilation needs of various industrial and commercial places. It combines multiple advantages such as high efficiency, reliability, and durability, and can operate stably in different environments, providing users with high-quality ventilation solutions.
（1） Rated voltage
The rated voltage of the fan is 230V, which is a common industrial and commercial voltage standard. A stable voltage supply is the foundation for the normal operation of wind turbines, and the rated voltage of 230V enables the wind turbine to be widely used in various power systems. During use, users need to ensure the stability of the power supply voltage to avoid damage to the fan caused by voltage fluctuations. For example, high voltage may cause the motor to overheat and burn out, while low voltage may prevent the fan from reaching its rated speed, affecting the ventilation effect.
（2） Size
The size of the fan is 250 millimeters, which gives it good versatility and installation flexibility due to its moderate size. Compared to smaller sized fans, it can provide greater air volume and pressure; Compared to larger sized fans, it has certain advantages in terms of installation space and cost. In practical applications, users can choose the appropriate installation location and method for the fan based on their specific installation environment and ventilation needs.
（3） Maximum air volume
The maximum air volume can reach 1655 cubic meters per hour, which is an excellent air volume indicator that enables it to meet the needs of large-scale ventilation. In some large industrial plants, commercial complexes and other places, it is necessary to quickly and effectively achieve air replacement and circulation. The high air volume characteristics of this fan can well meet this requirement. For example, in a large warehouse, the fan can quickly exhaust the polluted air inside the warehouse and introduce fresh air, improving the air quality inside the warehouse.
（4） Maximum pressure
The maximum pressure is 2900Pa, and the high pressure output capacity enables the fan to overcome significant ventilation resistance. In ventilation systems, there may be longer air ducts, bends, filters, etc., which increase the resistance to air flow. The high pressure characteristic of this fan ensures that air can still be smoothly delivered to the designated location after overcoming these resistances. For example, in a factory workshop with long ventilation ducts and many bends, this fan can ensure that the air is evenly distributed throughout the ventilation system, achieving good ventilation effects.
（5） Input power
The input power is 1117W. Although the power of the fan is relatively high, this is also to achieve its high air volume and high pressure performance. In actual operation, users need to choose the appropriate operating mode of the fan according to their ventilation needs in order to achieve energy-saving goals. For example, during periods of low ventilation demand, the fan speed can be appropriately reduced to reduce power consumption. At the same time, ebm-papst also adopted a series of energy-saving technologies in the design of the fan to improve its energy utilization efficiency.
（6） Rotational speed
The speed is 5005rpm, and a stable high speed is one of the key factors for the fan to achieve high air volume and high pressure output. High speed enables the impeller to rotate rapidly, thereby driving the air to flow quickly. However, high speed also puts forward higher requirements for the structural design, material selection, and manufacturing process of the fan. The fan adopts high-quality materials and advanced manufacturing processes to ensure stable operation at high speeds, reducing vibration and noise.
（7） Noise
The noise level is 79dB, and during operation, the fan inevitably generates a certain amount of noise. Although 79dB noise is relatively high, it is acceptable in some industrial environments. In order to reduce the impact of noise on the surrounding environment and personnel, the fan has adopted some noise reduction measures in its design, such as optimizing the shape and structure of the impeller, and using sound-absorbing materials. At the same time, when installing the fan, users can also take some additional noise reduction measures, such as installing soundproof covers and arranging the position of the fan reasonably.
（1） Efficient aerodynamic design
The G3G250-GN17-01 centrifugal fan adopts advanced aerodynamic design concepts. The shape of the impeller and the angle of the blades have been carefully optimized to maximize the efficiency of air intake and exhaust. During the operation of the fan, air can smoothly pass through the impeller, reducing the resistance and energy loss of air flow, thereby improving the overall performance of the fan. This efficient design enables the fan to generate greater air volume and pressure under the same power input, achieving effective energy utilization.
（2） High quality materials and exquisite manufacturing techniques
In order to ensure the reliability and durability of the fan, the selection of materials for the fan is very strict. The impeller is usually made of high-strength aluminum alloy or stainless steel material, which has good corrosion resistance and mechanical properties, and can withstand the huge centrifugal force and airflow impact generated during high-speed rotation. The casing is made of sturdy steel or engineering plastic, which has good protective performance and can effectively resist external impacts and corrosion. At the same time, exquisite manufacturing techniques ensure the accuracy and assembly quality of each component, reduce vibration and noise during operation, and improve the stability and reliability of the fan.
（3） Reliable motor performance
The fan is equipped with a high-performance motor, which has good starting and speed regulation performance (please consult customer service for specific functions of this product). At startup, the motor can quickly reach its rated speed, ensuring that the fan can be put into operation quickly. The insulation level of the motor is relatively high, and it can operate stably under different environmental temperature and humidity conditions. In addition, the motor is equipped with comprehensive protection devices such as overload protection, overheating protection, etc., which can automatically cut off the power supply in case of abnormal situations, protect other components of the motor and fan from damage, and extend the service life of the fan.
（4） Flexible installation method
Considering the installation needs of different users, G3G250-GN17-01 centrifugal fan provides multiple flexible installation methods. It can be installed horizontally, vertically, or diagonally, and users can choose according to the actual installation space and layout of the ventilation system. Meanwhile, the inlet and outlet directions of the fan can also be adjusted as needed to facilitate connection with different pipeline systems. This flexible installation method enables the fan to better adapt to various complex installation environments, improving its application flexibility and adaptability.
（5） Good compatibility
This fan can be well compatible with various ventilation systems and equipment. It can be used in conjunction with air filters, heat exchangers, ducts, and other equipment to form a complete ventilation and air treatment system. In addition, the fan can also be connected to an intelligent control system (please consult customer service for specific functions of this product) to achieve automated operation and regulation, improving the efficiency and management level of the ventilation system.
（1） Industrial ventilation
In industrial production fields such as steel, chemical, and machinery manufacturing, a large amount of pollutants such as heat, dust, and harmful gases are generated. The G3G250-GN17-01 centrifugal fan can be used in the ventilation system of industrial plants to discharge indoor polluted air and introduce fresh air, improve the working environment, and protect the health of employees. Its high pressure and large air volume characteristics can effectively overcome the resistance of ventilation ducts, ensuring that air can be transported to every corner of the factory building.
（2） Commercial building ventilation
Commercial buildings such as shopping malls, hotels, and office buildings are densely populated and have high requirements for air quality and comfort. This fan can be used in the central air conditioning system, ventilation duct system, and air purification equipment of commercial buildings to provide sufficient fresh air indoors, discharge polluted air, regulate indoor temperature and humidity, and improve indoor comfort. Meanwhile, its relatively high noise level can be controlled in commercial buildings through reasonable installation and sound insulation measures.
（3） Air purification equipment
In the field of air purification, this fan can serve as the core component of air purification equipment, providing powerful air power for the equipment. It can quickly pass the air through a filter, removing pollutants such as particulate matter and harmful gases from the air, and improving the purification efficiency of the air. Whether it is a household air purifier or an industrial grade air purification equipment, the G3G250-GN17-01 centrifugal fan can play an important role.
（4） Mechanical equipment heat dissipation
For some large mechanical equipment, such as generators, transformers, CNC machine tools, etc., a large amount of heat is generated during operation, and effective heat dissipation measures are needed. This fan can be installed in the cooling system of these devices to quickly dissipate the heat generated by the equipment through forced ventilation, maintaining the normal operating temperature of the equipment and extending its service life.
The ebm-papst G3G250-GN17-01 centrifugal fan has significant advantages in the fields of ventilation and air treatment due to its excellent parameter performance, unique product features, and wide range of applicable scenarios. Its efficient aerodynamic design, high-quality materials, and exquisite manufacturing process ensure the high performance and reliability of the fan; The flexible installation method and good compatibility enable it to adapt to various complex application environments. In the future development, with the continuous advancement of technology and the increasing demand of users, we believe that this fan will be continuously optimized and upgraded to provide users with better and more efficient ventilation solutions.
