W3G800-GU21-03 is a 400 V EC axial fan intended for dry coolers and related air-moving or cooling equipment.
| Brand: | ebm-papst |
| Part No.: | W3G800-GU21-03 |
| Fan Type: | Axial Fan |
| Rated Voltage (V): | 400 |
| Size (mm): | 800 |
| Max. Air Flow (m³/h): | 28910 |
| Max. Pressure (Pa): | 260 |
| Input Power (W): | 3025 |
| Speed (RPM): | 1100 |
| Noise (dB): | 77 |
W3G800-GU21-03 is an 800 mm EC axial fan for large-volume air movement across heat exchangers and ventilation equipment. Select it from the required airflow and pressure duty point, not from diameter alone.
Replacement checks should include the 800 mm size, 400 V supply, EC motor configuration, mounting arrangement, control connections and heat-exchanger resistance. Other W3G800 variants may not be electrically or aerodynamically equivalent.
W3G800-GU21-03 is currently shown as out of stock on the product page. Availability, lead time and minimum order quantity may vary with quantity and supply conditions. Provide the complete part number and delivery destination when requesting current procurement information.
