The ebm-papst M4Q045-EF01-01 is a 45 mm motor size q motor operating from 230 VAC. It is designed for refrigeration and ventilation equipment requiring a compact external-rotor Q motor.
| Brand： | ebm-papst |
| Part No： | M4Q045-EF01-01 |
| Fan Type： | Motor |
| Rated Voltage(V)： | 230 |
| Motor Size(mm)： | 45 |
| Max.Air Flow(m³/h)： | N/A |
| Max.Pressure(Pa)： | N/A |
| Input Power(W)： | 110 |
| Speed(rpm)： | 1300 |
| Noise(dB)： | N/A |
| Weight: | 2.2 kg |
| Bearing Shield Material: | Die-cast aluminum |
| Direction of Rotation: | Counterclockwise, viewed toward rotor |
| Degree of Protection: | IP42; installation- and position-dependent |
| Insulation Class: | "B" |
| Moisture (F) / Environmental (H) Protection Class: | H1 |
| Installation Position: | Any, preferably horizontal |
| Condensation Drainage Holes: | None |
| Mode: | S1 |
| Motor Bearing: | Calotte bearing |
| Touch Current according to IEC 60990 (measuring circuit Fig. 4, TN system): | < 0.75 mA |
| Motor Protection: | Thermal overload protector (TOP) internally connected |
| With Cable: | Lateral |
| Protection Class: | I (with customer connection of protective earth) |
| Conformity with Standards: | EN 60335-1; CE |
| Approval: | VDE; EAC |
